CF-09501055A

Name: CF-09501055A - Filtronetics
SKU: CF-09501055A
Availability: InStock

Bandpass Filters - Filters

Capabilities

Model Number:

CF-09501055A

Frequency

950 MHz

Insertion Loss

1.7 dB Max at Fo

Pass Bandwidth

±52.5 MHz / 3.0 dB Max

Stop Bandwidth

440 MHz / 70 dB Min

Ripple

1.0 dB Max in BW

Case

21 x 15 x 5.5 mm (SMD)

Operating Temperature

-40 to + 75 °C

Poles

Impedance

50 Ohms

Cutoff Frequency

Frequency Range

High Center Frequency

High Pass Bandwidth

Load

Low Center Frequency

Low Pass Bandwidth

Rise/Fall Time

Size

Type of filter

Bandpass

Logic

Sort

Type
