0 products found.
Model Number
Frequency
Pass Bandwidth
Stop Bandwidth
Insertion Loss
Ripple
Case
Frequency
850 MHz
Pass Bandwidth
25 MHz / 3.0 dB Max
Stop Bandwidth
75 MHz / 40 dB Min // 100 MHz / 60 dB Min
Insertion Loss
4.5 dB Max at Fo
Ripple
Case
38.0 x 16.0 x 8.0 mm (SMD)
Frequency
850 MHz
Pass Bandwidth
±52.5 MHz / 1 dB Max
Stop Bandwidth
250 MHz / 45 dB Min
Insertion Loss
2.2 dB Max at Fo
Ripple
1.0 dB Max inPB
Case
38.1 x 12.7 x 7.6 mm (SMD)
Frequency
860 MHz
Pass Bandwidth
±12.5 MHz / 0.5 dB Max
Stop Bandwidth
At 780 MHz / 80 dB // At 930 MHz 30 dB Min
Insertion Loss
2.2 dB Max at Fo
Ripple
0.5 dB Max in PB
Case
38.0 x 16.0 x 8.0 mm (SMD)
Frequency
874 MHz
Pass Bandwidth
±15 MHz / 3.0 dB Max // 50 MHz / 3.0 dB Max
Stop Bandwidth
At 250 MHz to 500 MHz / 60 dBc Min // At 930 MHz to 1GHz / 50 dBc Min
Insertion Loss
3.3 dB Max at Fo
Ripple
Case
26.0 x 16.5 x 5.6 mm (SMD)
Frequency
885 MHz
Pass Bandwidth
±5 MHz / 0.6 dB Max
Stop Bandwidth
'@ Fo 60 MHz / 55 dBc Min // @ Fo + 60 MHz / 55 dBc Min
Insertion Loss
4.2 dB Max @ Fo±5MHz
Ripple
0.6 dB Max @ Fo±5MHz
Case
17 x 14 x 4.3 mm (SMD)
Frequency
889 MHz
Pass Bandwidth
±20 MHz / 1 dB Max
Stop Bandwidth
120 MHz / 40 dB Min
Insertion Loss
2.0 dB Max at Fo
Ripple
Case
37.16 x 15 x 7.5 mm (SMD)
Frequency
900 MHz
Pass Bandwidth
±100 MHz / 3.0 dB Max
Stop Bandwidth
At 640 MHz / 60 dB Min // At 1150 MHz / 55 dB Min
Insertion Loss
3.0 dB Max in PB
Ripple
Case
26.5 x 14 x 5.5 mm (SMD)
Frequency
925 MHz
Pass Bandwidth
25 MHz / 3.0 dB Max
Stop Bandwidth
75 MHz / 40 dB Min // 100 MHz / 60 dB Min
Insertion Loss
4.3 dB Max at Fo
Ripple
Case
38.5 x 16.5 x 8.0 mm (SMD)
Frequency
925 MHz
Pass Bandwidth
±85 MHz / 3.0 dB Max
Stop Bandwidth
400~1300 MHz / 60 dB Min // 1100~1500 MHz / 40 dB Min
Insertion Loss
4.0 dB Max
Ripple
1.5 dB Max
Case
26 x 16 x 5.5 mm (SMD)
Frequency
940 MHz
Pass Bandwidth
25 MHz / 1.0 dB Max
Stop Bandwidth
At 900 MHz / 50 dB Min // At 980 MHz / 48 dB Min
Insertion Loss
3.5 dB Max in Fo
Ripple
Case
26.5 x 15 x 5.5 mm (SMD)
Frequency
942.5 MHz
Pass Bandwidth
±17.5 MHz / 1.0 dB Max
Stop Bandwidth
DC~790 MHz / 60 dB Min // 790~870 MHz / 45 dB Min // 1220~2200 MHz / 60 dB Min // 2200~3000 MHz / 50 dB Min
Insertion Loss
4.0 dB Max in BW
Ripple
1.0 dB Max in BW
Case
26.2 x 25.2 x 5.2 mm (SMD)
Frequency
950 MHz
Pass Bandwidth
±52.5 MHz / 1.0 dB Max
Stop Bandwidth
250 MHz / 45 dB Min
Insertion Loss
2.2 dB Max at Fo
Ripple
1.0 dB Max in PB
Case
38.1 x 14.7 x 7.6 mm (SMD)
Frequency
960 MHz
Pass Bandwidth
±10 MHz / 3.0 dB Max
Stop Bandwidth
DC~480MHz / 70 dB Min // 1920~2100MHz / 70 dB Min
Insertion Loss
3.0 dB Max at Fc
Ripple
1.0 dB Max in Pass Band
Case
26.5 x 14.0 x 5.5 MHz
Frequency
960 MHz
Pass Bandwidth
100 MHz / 3.0 dB Max
Stop Bandwidth
Fo-110MHz / 55 dB Min // Fo+110MHz / 43 dB Min
Insertion Loss
3.0 dB Max
Ripple
Case
26.5 x 15 x 5.5mm (SMD)
Frequency
993 MHz
Pass Bandwidth
62 MHz / 3.0 dB Max
Stop Bandwidth
At 953 MHz / 10 dBc Min // At 1033 MHz / 10 dBc Min
Insertion Loss
2.2 dB Max at Fo
Ripple
3.0 dB Max in Fo+/-31 MHz
Case
38 x 17 x 7.5 mm (SMD)
Frequency
993 MHz
Pass Bandwidth
62 MHz / 1.7 dB Max
Stop Bandwidth
At 933 MHz / 15 dBc Min // At 1053 MHz / 15 dBc Min
Insertion Loss
1.7 dB Max at Fo
Ripple
0.7 dB Max in Fo+/-31 MHz
Case
38 x 17 x 7.5 mm (SMD)
